| Brand Name: | cheebo |
| Model Number: | CBLD-5A |
| MOQ: | 1 set |
| Price: | NEGOTIABLE |
| Packaging Details: | Marine moisture-proof wooden case |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram, |
● Welding of power lithium-ion battery modules, 3C lithium-ion battery packs, nickel hydrogen battery packs, hardware components, electronic and electrical parts, wire terminals, stainless steel parts, metal jewelry, copper products, aluminum products, etc. It is also applicable to product maintenance and sampling work.
● Independently developed precision welding machine head, with precise adjustable welding pressure and buffering pressure adjustment mechanism, can effectively reduce damage to battery cells during welding.
● The height of the welding head of the equipment can be adjusted up and down. The minimum height of the battery should not be less than 50MM, and the maximum height should not exceed 130MM (the height of the raised version is 230MM). Welding can be carried out within this range.
● Can store welding parameters, a total of 63 sets of welding parameters can be stored, welding nickel sheets of different thicknesses, can be easily accessed, simple and time-saving.
●The output current has polarity switching function, effectively eliminating the polarity (bipolar) that occurs during the welding process,Designed with side out electrodes, it is easier to assemble on automated equipment,Adopting industrial grade circuit design, the circuit is safe, reliable, and has a low failure rate,The device has an exquisite appearance, superior structural design, compact and reasonable structure, small size, and high power.
Power on - Check if the WELED switch is turned on - Turn on the motion control system power - Welding head action - Find the origin position -
Place the product to be welded on the desktop - Step on the foot pedal - Press down the welding head - Spot welding is completed - Welding
head returns to its original position
| Welding thickness | 0.04-0.2mm (if it exceeds 0.2mm, a flow channel or convex point needs to be opened) | Welding power supply | Transistor |
| Welding mode | Single side double point horizontal welding | Table top and weld head height | 130mm (with an additional height of 230mm) |
| Supply current | 5000A/8000A/10000A | Welding speed | 80P/M |
| Spot welding method | Bump welding/tip welding | Welding pressure | 5KG/F |
| Maximum voltage | 30V(Adjustable by oneself) | Equipment size | 900mm*1150mm*1750mm |
| Driving mode | Electric | Machine Weight | 70KG |
| Power source specification | single-phase 220V 50/60HZ 450W | Application scenarios | Battery welding |
1. Electric control
No additional air source, low noise, fast welding speed, stable pressure.
2.Electric precision welding head
Motor driven welding, without the need for external solenoid valves and cylinders, with low noise. Horizontal welding structure, double linear guide rail design, left and right pressure can be adjusted separately. Built in pressure sensor for precise control and stable pressure application.
3. Thickened tempered glass
High quality explosion-proof glass is used to effectively prevent the damage caused to the desktop during welding. At the same time, it can increase the fluency of welding and increase the welding efficiency.
1) Maintain a distance of 3-5MM between the welding needle end face and the battery end face
2) The battery specifications within a battery pack must have the spot welding surface level and the height as consistent as possible
3) Regularly clean the end face of the welding needle for spot welding
Q: How do I install and run the machine?
A: Our technicians had installed the machine before shipment. For the installation of some widgets, we will send out detailed training videos and user manuals randomly. 95% of customers can teach themselves.
Q: How can I do if the machine goes wrong?
A: If you encounter such problems, please contact us as soon as possible. Do not try to repair the machine by yourself or others. We will respond as soon as possible within 24 hours to solve your problem.
Q: I don't know which one is right for me?
A: Please tell us the following information
1) Battery model and type.
2) Welding material and welding thickness
3) Commercial industry: We have a lot of sales experience and can provide you with advice.
Q: What's your minimum order quantity?
A: We don't have a minimum order quantity. Whether it is an order of 1 or 100, we will wholeheartedly support you.
Q: How does your factory do in terms of quality control?
A: Quality comes first. More than 20 tests will be performed on each unit. After all the tests are passed, our QC will test the welding performance.
